سوئیچ شبکه اترنت 16 پورت گیگ دارای پهنای باند 32Gbps اچ آر یو آی HRUI HR-SWG10160D-M
HRUI HR-SWG10160D-M
– سوئیچ 16 پورت اترنت گیگ
– سوئیچ اترنت گیگ
– 30 ماه وارانتی بی قید و شرط
ضمانت اصالت کالا
امکان تحویل اکسپرس تهران
ضمانت کمترین قیمت کالا
عنوان | نوع فایل | حجم | دانلود |
Data Sheet | PDF | 320KB |  |
برند
HRUI
مدل
HRUI HR-SWG10160D-M
Power
AC input (100-240V)
Ethernet
16xRJ45 10/100/1000Mbps Ports
Bandwidth
32Gbps
Pack forward rate
23.8Mpps
Packet Buffer
4M
MAC Address
8K
Jumbo Frame
4K
Transfer Mode
Store and forward
MTBF
100000 hour
Network protocol
IEEE802.3 (10Base-T)
IEEE802.3u (100Base-TX)
IEEE802.3ab (1000Base-TX)
IEEE802.3x (Flow control)
Industry Standard
EMI: FCC Part 15 CISPR (EN55032) class A
EMS: EN61000-4-2 (ESD)
EN61000-4-5(Surge)
Network Medium
10Base-T : Cat3, 4, 5 or above UTP(≤100m)
100Base-TX : Cat5 or above UTP(≤100m)
1000Base-TX : Cat5 or aboveUTP(≤100m)
Security Certificate
CE, FCC, RoHS
Working Environment
Working Temperature: -10~50°C
Storage Temperature: -40~70°C
Working Humidity: 10%~90%，non-condensing
Storage Temperature: 5%~90%，non-condensing
Structure Size
Product Size: 220*161*44mm
Package Size: 315*215*85mm
Product Net-Weight: 0.90kg
Product Gross-Weight: 1.42kg (With mount ear) 1.24kg (without mount ear)
Packing Info
MEAS: 445*455*335mm
Packing Qty: 10 unit
Packing weight：15.2KG (With mount ear) 13.4kg (without mount ear)
Power Voltage
Input Voltage: AC 100-240 V
Output Voltage：12V1A
Package List
Switch 1 pcs, Power cord 1 pcs, User manual 1 pc, Warranty card 1 pc, Brackets 1 pair
DIP Switch
VLAN：Port Isolation, 1-14 ports are isolated each other, all communicate with uplink port 15/16;
Default：Default mode, Support loop alarm;
Extend：Monitor Mode, 1-14 ports support 100M speed reduction negotiation, support 150 meters in 100Mbps/s mode, port 15 and port 16 as uplink port；
